Fedar Digital Sublimation Textile Printer FD6194E, Sublimation Printer with EPS3200 Head, Heat Transfer Printer, Best Chinese Sublimation Printer

Main Features Printer Details Specification Related Videos Application Inquiry

Main Features

High Resolution Printhead

4 Epson I3200-A1 printhead,2 pass speed can reach up to 150㎡/h

High-end Software

Using international high-end software, the drawing is more realistic.

Intelligent Ink Starving Alarm

Reduces the tediousness of frequently checking the remaining amount of ink, and at the same time reminds to add ink in time to ensure the continuity of printing work.

Intelligent Foggy Printing & VSDT Printing

Unique two-dimension intelligent foggy and wave-foggy function, and VSDT variable droplet techonology, improve printing quality obviously.

Using Advanced Capping Station

Equipped with advanced intelligent printhead cleaning and moisturizing device, providing safe and convenient printhead cleaning and maintenance functions, more convenient operation and maintenance.

Stable Media Feeding and Take-up System

Convenient,the printing media is quickly stored,equipped with automatic paper measurement and anti-rubbing function,the consumables are warped,printing is automatically paused to prevent scratching the printhead.

Printer Details

Specially Designed Car

The position of the print head can be adjusted according to different printing medias, and anti-collision devices at both ends to give the print head more comprehensive safety protection.

Chinese Leadshine Motor

The two-way Leadshine brushless motor has higher accuracy, smaller length error and more stable performance.

Large Capacity Ink Reservoirs

Four units of 3L super large capacity ink reservoirs provide ink independently and continuously, which guarantees the long-term continuity of ink output.

Intelligent Air-heat Dryer

The intelligent drying system is synchronized with printing, saving energy and reducing emissions. During the printing process, the temperature can be adjusted in real time according to the actual situation.

THK Mute Guide Rail

Using Japanese THK mute linear guide rail, the movement is more stable and the life is longer.

Germany IGUS Ink Chain

Imported Germany IGUS ink chain,high quality, to ensure the good completion of printing work.

Fluororubber Pressure Roller

US fluororubber pressure roller prevents static electricity from flying ink, prints more accurately and rejects wrinkles

Two-level Ink Supply System

Adopt two-level ink supply system, continuous printing for a long time to ensure the output quality of the picture.

Specification

Printer Model		FD6194E
Printhead	Type	EPSON I3200-A1
	Nozzle Qty	8004lines4pcs printheads
	Height to Platform	2-5mm
Printing Speed	Production Mode	2pass/360*1200dpi 150sqm/h
	Average Mode	3pass/360*1800dpi 110sqm/h
	High Resolution Mode	4pass/720*1200dpi 90sqm/h
Ink	Color	C M Y K
	Type	Dye Sublimation
	supply method	Siphoning
Max Printing Width		1900mm
Printing Media		Transfer Paper
Media Transfer Method		Auto air shaft feeding and take-up system
Drying Method		External,Intelligent and air-heat Integrated drying system
Moisture Mode		Fully sealed auto moisturing and cleaning
RIP Software		Maintop6.0,Photoprint,Onyx,Wasatch and NeoStampa and etc.
Image Format		JPG,TIF,PDF,BMP and etc.
Computer	System	WIN7 64bit/WIN10 64bit
	Hardware	Hard disk:500G (system disk more than 100G) GPU:ATI Discrete CD-ROM:DVD ROM Memory:4G or more CPU:Intel i5/i7 processor
	Transmit Port	Gigabit LAN
Work Environment		Temperature 20-35 centi degree; Humidity 35-65%
Power	Input Voltage	210-230VAC 50/60HZ 16A
	Printing system	1500W
	Drying system	Max power 7000W
Dimension	Printer Dimension	328410501720mm
Dimension	Packing Dimension	346011501870mm
Weight	Net Weight	650KG
Weight	Gross Weight	780KG

4 Heads & 1.9m FD6194E
